GSW-2620HP- идеальный гигабитный PoE коммутатор. Обеспечивает экономичное преимущество для локальных вычислительных сетей малого и среднего бизнеса.
- 24-port 10/100/1000BASE-T Gigabit RJ45 (24-порта 802.3af/802.3at PoE Injector)
- 2 1000BASE-X mini-GBIC/SFP слот
Power over Ethernet (PoE):
- Соответствует IEEE 802.3at High Power over Ethernet
- Соответствует IEEE 802.3af Power over Ethernet
- 24 порт IEEE 802.3af/802.3at
- Поддержка PoE Power до 30.8 W для каждого PoE порта
- Каждый порт поддерживает 52V DC для PoE устройства
- 220 W PoE бюджет
Physical Port
- 24-port 10/100/1000BASE-T Gigabit RJ45 copper
- 2 1000BASE-X mini-GBIC/SFP slots
Power over Ethernet
- Complies with IEEE 802.3at High Power over Ethernet
- Complies with IEEE 802.3af Power over Ethernet
- Up to 24 ports of IEEE 802.3af/802.3at devices powered
- Supports PoE Power up to 30.8 watts for each PoE port
- Each port supports 52V DC power to PoE Powered Device
- 220-watt PoE budget
- Auto detects powered device (PD)
- Circuit protection prevents power interference between ports
- Remote power feeding up to 100m
Switching
- Hardware based 10/100/1000Mbps auto-negotiation and auto MDI/MDI-X
- Flow control for full duplex operation and back pressure for half duplex operation
- Integrates address look-up engine, supporting 8K absolute MAC addresses
- 9K jumbo frame supports all speeds (10/100/1000Mbps)
- IEEE 802.1Q VLAN transparency
- Automatic address learning and address aging
- Supports Energy-Efficient Ethernet (EEE) function (IEEE 802.3az)
Hardware
- 19-inch desktop size, 1U height
- LED indicators for PoE ready and PoE activity
- Ethernet Link Energy-saving technology
- Link down power saving
- Intelligent scale power based on cable length
Hardware Specifications |
|
10/100/1000BASE-T Copper Ports |
24 auto-MDI/MDI-X ports |
802.3af/802.3at PoE Injector Ports |
24 |
1000BASE-X SFP/mini-GBIC Slots |
2 |
Switch Architecture |
Store-and-Forward |
Switch Fabric |
52Gbps/non-blocking |
Switch Throughput@64 bytes |
38.6Mpps@64 bytes |
MAC Address Table |
8K entries |
Jumbo Frame |
9216 bytes |
Flow Control |
IEEE 802.3x pause frame for full-duplex; back pressure for half-duplex |
LED |
System: Power (Green) |
Dimensions (W x D x H) |
445 x 207 x 45 mm (1U height) |
Enclosure |
Metal |
Weight |
2.85kg |
Power Requirements |
100~240V AC, 50/60Hz, 4A (max.) |
Thermal Fan |
2 |
Power over Ethernet |
|
PoE Standard |
IEEE 802.3af Power over Ethernet/PSE |
PoE Power Output |
Per port 52V DC, 300mA. max. 15.4 watts (IEEE 802.3af) |
PoE Power Budget |
220 watts |
Number of PDs, 7 watts |
24 |
Number of PDs, 15.4 watts |
14 |
Number of PDs, 30 watts |
7 |
Standards Conformance |
|
Regulatory Compliance |
FCC Part 15 Class A, CE |
Standards Compliance |
IEEE 802.3 10BASE-T |
Environment |
|
Operating |
Temperature: 0 ~ 50 degrees C |
Storage |
Temperature: -10 ~ 70 degrees C |
